Product Features
● The maximum power consumption is 3.5W
● Complies with QSFP standards for hot swappable
● Equipped with digital optical monitoring function, providing powerful diagnostic capabilities.
● Tested in the target switch to ensure its excellent performance, quality, and reliability
● Compliant with SFF-8436 and QSFP MSA standards
Each channel supports a maximum data transmission rate of 10.3125Gb/s, catering to diverse rate requirements and adapting to high-performance network applications. With a maximum transmission distance of up to 300 meters on OM3 fiber, it provides an efficient short-distance fiber optic communication solution. The product adopts a QSFP+ form factor and supports hot-pluggable design, allowing for easy replacement or installation of modules without disrupting system operations, thereby enhancing system availability. Each optical module includes 4 channels and supports full-duplex data transmission, enabling efficient handling of large data streams and meeting the demands of large-scale data centers and network switching environments.
Specifications
| Model | QSFP 40G SR4 300M | line type | MPO |
| Wavelength | 850nm | Maximum transmission distance |
300m |
| Cable type | MMF | Transmission speed | 40 Gbps |
|
TX power (dBm) |
-6~2.4 |
RX sensitivity (dBm) |
-10.3 |
|
Power consumption (W) |
<1.5W |
Working temperature |
0~70° |
| Extinction ratio | >3.5dB | Compliant with standards | SFF-8665 MSA |
